D4R Pro Dovetail Jig – Metric Model (Item D4RPro M)

$1,069.00

Item D4RPro M

Leigh Dealers may carry this product, please visit www.leightools.com/dealer-usa/ to find a dealer near you.





SKU: D4RPro M Category: Tags: , ,

Description

D4R Pro Dovetail Jig – Metric Model

The Leigh D4R Pro is the most versatile and user-friendly dovetail joinery jig available, and with it, you can create perfect joinery of all kinds: through dovetails, half-blind dovetails, sliding dovetails and box joints (finger joints). In just minutes, you can rout equally or variably spaced through and half-blind dovetails, not possible with template jigs.

Note: The D4RPro M requires a router with a 1/2″ collet

Additional information

Jig Body

Machined Aluminum Extrusion

Jig Body End Housings

Cast Metal

Finger Style

2-piece

Sidestops

CNC Machined In

Clamping Mechanism

Cam-Action Speed-Clamp

Clamping Surface

Machine Textured

Clamp Bars

Trapezoid Aluminum

Crosscut Fence

Rigid Plastic Extrusion

Bridge Piece Material

Rigid Plastic Extrusion

Maximum Board Thickness

1-1/2"

Minimum Board Thickness

1/8"

Minimum Board Width

1"

Max.Through Pin/Tail Board

Pin 1-1/4", Tail 1-1/2"

Max.Half-Blind Board

1-1/2"

Variably Spaced Through

YES

Variably Spaced Half-Blind

YES

Single Pass Half-Blind

YES

Sliding Dovetails

YES

Box Joints w/DT Finger

3/8" & 3/4" Adjustable Fit

Box Joints w/Optional Temp

11 sizes

End-on-End Dovetails

YES

Asymmetrical Joints (Through)

YES

Simple Angle Joints

YES

Obtuse Angle Joints

YES

Acute Angled Joints

YES

Compound Angled Joints

YES

Needle Pins

YES

Shelf Holes & Shelf Notches

YES

What’s Included

The D4R Pro comes with:
  • Instructional user guide
  • Bridge piece material
    for half-blind joints
  • Stop rod and spacer for single pass half-blind dovetails
  • 1/2″ 8° dovetail bit
  • 1/2″ 14° dovetail bit
  • 5/16″ straight bit
  • 1/2″ to 8mm collet reducer
  • Spacer for box/finger joints
  • Sliding dovetail fence

  • e7 guide bushing and pin wrench for joint fit adjustment
  • 5/64” hex key
  • Square drive screwdriver
  • Wrench / gauge
